Physical Interfaces:

• 1 X Gigabit Ethernet (1000Mb/s) Ports
• 3 X Megabit (100Mb/s) Ports
• ADSL Port (RJ11)
• Secondary WAN Port : 10/100 Base-TX Ethernet for load balance and WAN failover
• USB Port for 3G Cellular Modem or Printer
• 1 Analogue Telephone Port
• 1 Analgoge Line Port

IP PBX Features:

• Up to 50 Extension profiles (user/phone accounts)
• Up to 30 simultaneous registered extensions - local or remote
• Up to 20 simultaneous calls
• Registration and authentication
• FXO Port (analogue line interface) fully integrated with PBX - New!
• BLF (Busy-lamp Field)
• Hunting Group with Overflow - New!)
• Selective CLI for outgoing calls - New!
• IVR (Interactive Voice Menus for callers - Auto Attendant)
• Call forwarding - to extensions or external PSTN - New!
• Calendar
• Dial Plan (Phone Book)

VoIP Protocols:

• SIP, RTP/ RTCP
• SRTP/ZRTP for VoIP Encryption for analogue phone port
• Up to 6 simultaneous SIP registrars (trunks)
• G.168 line echo-cancellation
• Automatic gain control
• Jitter buffer (180ms)
• Voice codecs : G.711, G.723.1, G.726,VAD/CNG, (iLBC Planned for future)
• DTMF tone : Inband / Outband (RFC-2833)/ SIP Info
• FAX/Modem support : Tone detection / G.711 pass-through / T.38* for FAX

Operating Requirements

• DHCP Client/Server
• DHCP Options
• Dynamic DNS Service Updating
• NTP Client
• DNS Cache/Proxy
• Static Routing

NAT (IPv4):

• 100,000 Sessions
• Port Redirection
• One-to-One Public-to-Private Mappping
• MultiNAT

VPN:

• Dial-in and Dial-out LAN-to-LAN
• Dial-in Teleworker

Protocols

• PPTP
• L2TP
• IPSec
• L2TP over IPSec

Encryption/authentication::

• Hardware-based AES (128, 192, 256 bits)
• Hardware-based DES/3DES (56 & 168 bits)
• MPPE (40 or 128 bits)
• Hardware-based MD5 & SHA-1
• IKE authentication : Pre-shared Key (PSK)
• PKI : X.509 Digital Signature (certificate)
• Certificate Server (CA) / Trusted CA / Local Certificate
• MOTP for Teleworkers
• Dead Peer Detection (DPD)
• VPN Passthrough : PPTP, L2TP, IPSec, SSL
• NAT Traversal (NAT-T)
• DHCP over IPSec
• GRE over IPSec

Routing Functions:

• IPv4 & IPv6 Dual-Stack
• Note : IPv6 is available on only a single WAN port
• DNS Cache/Proxy
• DHCP Client, Server & Relay
• DHCP Options: 1,3,6,51,53,54,58,59,60,61,66,125
• IGMP v1/v2 & Proxy/Snooping
• uPnP: 500 Sessions
• NAT: 80,000 Sessions
• NTP Client with DST Adjustments
• Static routing
• Policy-based routing
• Dynamic DNS : Updates DDNS servers with public IP address
• Port-Based VLAN
• Tag-Based VLAN: 802.1q
• Client/Call Scheduling : Real-time clock, with NTP updating schedules access or connectivity
• Wake-on-LAN : Passed from WAN to preset LAN device

Traffic / Content Management:

• QoS (7/2 levels egress/ingress)
• DiffServ Codepoint Classifying
• Session & Bandwidth Limitation (IP-based)
• Globalview Categoric Web Content Filtering
• Web URL Keyword Blocking

SSL VPN:

• Tunnel Mode : up to 200 Web Proxy Tunnels
• SSL Full tunnelling (firmare upgrade - schedule TBA)
• SSL Applications : HTTP (web), VNC, RDP
• Encryption : RC4 (128 bits), AES (128 bits), DES/3DES
• Digital Signature (X.509)
• Pre-shared key
• MOTP

Management Facilities:

• Web Interface (HTTP & HTTPS)
• CLI : Telnet and SSH
• Firmware Upgrade : TFTP and HTTP
• Configuration Backup/Restore (Binary)
• Admin Access Control
• SNMP Management (MIB-II))
• Syslog
• TR-069
• Supported by Vigor-ACS Platform

Management Facilities:

• Web Interface (HTTP & HTTPS)
• CLI : Telnet and SSH
• Firmware Upgrade : TFTP and HTTP
• Configuration Backup/Restore (Binary)
• Admin Access Control
• SNMP Management (MIB-II))
• Syslog
• TR-069
• Supported by Vigor-ACS Platform

Operating Requirements:

• Rack Mountable (Optional RM1 mounting bracket required)
• Wall Mountable
• Temperature Operating : 0°C ~ 45°C
• Storage : -25°C ~ 70°C
• Humidity 10% ~ 90% (non-condensing)
• Weight : 1.2Kg
• Power Consumption: 18 Watt Max.
• Dimensions: L240.96 * W165.07 * H43.96 ( mm )
• Operating Power: DC 15V (via external PSU, supplied). Max 21W.
• Warranty : Two (2) Years RTB
• Power Requirements : 220-240VAC
