Physical Interfaces:

• LAN Ports (Switch)
• 6 X Gigabit Ethernet (1000Mb/s) Ports
• Port-Based VLAN (Inclusive/Exclusive Groups)
• 802.1q VLAN Tagging

WAN Ports:

• WAN1 : ADSL/VDSL, RJ11
• WAN2 : Gigabit Ethernet (1000Mb/s) Ethernet for load balance and WAN failover
• WAN3 : USB Port for 3G Cellular Modem or Printer
• Phone Ports : 2 x BT Type sockets. FXS type. V2860Vn only.
• Line Port : For POTS/PSTN voice line connection (cable included). V2860Vn only.

Performance:

• Firewall: Up to 200Mb/s
• IPSec VPN: Up to 50Mb/s

ADSL Compatibility:

• ANSI T1.413 Issue2
• ITU-T G.992.1 G.dmt (ADSL)
• ITU-T G.992.2 G.lite
• ITU-T G.992.3 ADSL2
• ITU-T G.992.5 ADSL2+
• Annex L (READSL)
• Annex A
• Annex M
• ANFP Issue 3 Compliant/Certified (for Annex A & Annex M)
• DSL Forum : TR-048/67 & TR-100

VDSL Compatibility:

• BT Infinity Option 1 & Option 2 Compatible
• ITU-T VDSL2 G.993.2
• ITU-T G.993.1, G.997.1
• Band Plan: G.998, G.997
• Annex A, Annex B, Annex C
• VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a
• OLR, UPBO, DPBO Supported
• US0 Supported
• Loop Diagnostic Mode
• Configurable SNR, INP, Rate Limit
• DSL Forum WT-114

Load Balance/Failover Features:

• Outbound Policy-Based Load-Balance
• WAN Connection Fail-over
• BoD (Bandwidth on Demand)
• Vigor 2860 ATM Protocols (DSL):
• RFC-2684/RFC-1483 Multiple Protocol over AAL5
• RFC-2516 PPP over Ethernet
• RFC-2364 PPP over AAL5
• PPPoE pass through LAN/WLAN
• PPPoE/PPPoA Relay
• Transparent bridge for MPoA
• Multiple PVC support for Triple Play Applications (up to 8 simultaneous)

Wireless LAN Features ('n' Models Only):

• 802.11n
• Multiple SSID : Create up to 4 virtual wireless LANs (independent or joined)
• Packet Aggregation and Channel Bonding
• Optional Higher Gain or directional aerials available - Click Here.
• Compatible with 802.11b and 802.11g Standards
• Active Client list in Web Interface
• Wireless LAN Isolation (from VLAN groups and wired Ethernet interfaces)
• 64/128-bit WEP Encryption
• WPA/WPA2 Encryption
• Switchable Hidden SSID
• Restricted access list for clients (by MAC address)
• Time Scheduling (WLAN can be disabled at certain times of day)
• Access Point Discovery
• WDS (Wireless Distribution system) for WLAN Bridging and Repeating
• 802.1x Radius Authentication
• Wireless VLAN
• Wireless Rate-Control
• Automatic Power Management
• 802.11e WMM (Wi-Fi Multimedia)

VoIP Features (Vigor2860Vn only):

• Protocols: SIP, RTP / RTCP
• 12 SIP Registrar Accounts (for up to 12 VoIP providers)
• Line port for PSTN Passthrough (integrates POTS line)
• Auto-fallback to PSTN under power/Internet failure
• G.168 Line Echo-cancellation
• Automatic Gain Control
• Jitter Buffer ( 125ms )
• Voice Codecs:
• G.711 A / µ Law
• G.723.1
• G.726
• G.729 A / B
• VAD / CNG
• Tone Generation: DTMF , Dial , Busy , Ring Back , Call Progress
• DTMF Transmission: In Band / Out Band ( RFC-2833 ) / SIP info
• FAX / Modem Support G.711 Pass-through
• T.38 for FAX
• Supplemental Services:
• Caller ID
• Call Hold / Retrieve
• Call Waiting
• Call Waiting with Caller ID
• Call Transfer
• Call Forwarding ( Always , On Busy and On No Answer )
• DND (Do not Disturb)
• Call Barring ( Incoming / Outgoing )
• MWI ( Message Waiting Indicator ) ( RFC-3842 )
• Hotline (Dial preset number when handset lifted)

WAN Protocols (Ethernet):

• DHCP Client
• Static IP
• PPPoE
• PPTP
• L2TP *
• BPA

VoIP Features (Vigor2860Vn only):

• Protocols: SIP, RTP / RTCP
• 12 SIP Registrar Accounts (for up to 12 VoIP providers)
• Line port for PSTN Passthrough (integrates POTS line)
• Auto-fallback to PSTN under power/Internet failure
• G.168 Line Echo-cancellation
• Automatic Gain Control
• Jitter Buffer ( 125ms )
• Voice Codecs:
• G.711 A / µ Law
• G.723.1
• G.726
• G.729 A / B
• VAD / CNG
• Tone Generation: DTMF , Dial , Busy , Ring Back , Call Progress
• DTMF Transmission: In Band / Out Band ( RFC-2833 ) / SIP info
• FAX / Modem Support G.711 Pass-through
• T.38 for FAX
• Supplemental Services:
• Caller ID
• Call Hold / Retrieve
• Call Waiting
• Call Waiting with Caller ID
• Call Transfer
• Call Forwarding ( Always , On Busy and On No Answer )
• DND (Do not Disturb)
• Call Barring ( Incoming / Outgoing )
• MWI ( Message Waiting Indicator ) ( RFC-3842 )
• Hotline (Dial preset number when handset lifted)

WAN Protocols (Ethernet):

• DHCP Client
• Static IP
• PPPoE
• PPTP
• L2TP *
• BPA

VoIP Features (Vigor2860Vn only):

• Protocols: SIP, RTP / RTCP
• 12 SIP Registrar Accounts (for up to 12 VoIP providers)
• Line port for PSTN Passthrough (integrates POTS line)
• Auto-fallback to PSTN under power/Internet failure
• G.168 Line Echo-cancellation
• Automatic Gain Control
• Jitter Buffer ( 125ms )
• Voice Codecs:
• G.711 A / µ Law
• G.723.1
• G.726
• G.729 A / B
• VAD / CNG
• Tone Generation: DTMF , Dial , Busy , Ring Back , Call Progress
• DTMF Transmission: In Band / Out Band ( RFC-2833 ) / SIP info
• FAX / Modem Support G.711 Pass-through
• T.38 for FAX
• Supplemental Services:
• Caller ID
• Call Hold / Retrieve
• Call Waiting
• Call Waiting with Caller ID
• Call Transfer
• Call Forwarding ( Always , On Busy and On No Answer )
• DND (Do not Disturb)
• Call Barring ( Incoming / Outgoing )
• MWI ( Message Waiting Indicator ) ( RFC-3842 )
• Hotline (Dial preset number when handset lifted)

WAN Protocols (Ethernet):

• DHCP Client
• Static IP
• PPPoE
• PPTP
• L2TP *
• BPA

Firewall & Security Features:

• CSM (Content Security Management):
• URL Keyword Filtering - Whitelist or Blacklist specific sites or keywords in URLs
• Block Web sites by category (e.g. Adult, Gambling etc. Subject to subscription)
• Prevent accessing of web sites by using their direct IP address (thus URLs only)
• Blocking automatic download of Java applets and ActiveX controls
• Blocking of web site cookies
• Block http downloads of file types :
• Binary Executable : .EXE / .COM / .BAT / .SCR / .PIF
• Compressed : .ZIP / .SIT / .ARC / .CAB/. ARJ / .RAR
• Multimedia : .MOV / .MP3 / .MPEG / .MPG / .WMV / .WAV / .RAM / .RA / .RM / .AVI / .AU
• Time Schedules for enabling/disabling the restrictions
• Block P2P (Peer-to-Peer) file sharing programs (e.g. Kazza, WinMX etc. )
• Block Instant Messaging programs (e.g. IRC, MSN/Yahoo Messenger etc.)
• Multi-NAT, DMZ Host
• Port Redirection and Open Port Configuration
• Policy-Based Firewall
• MAC Address Filter
• SPI ( Stateful Packet Inspection ) with new FlowTrack Mechanism
• DoS / DDoS Protection
• IP Address Anti-spoofing
• E-Mail Alert and Logging via Syslog
• Bind IP to MAC Address

Bandwidth Management:

• QoS
• Guaranteed Bandwidth for VoIP
• Class-based Bandwidth Guarantee by User-Defined Traffic Categories
• Layer 2&3 (802.1p & TOS/DCSP)
• DiffServ Code Point Classifying
• 4-level Priority for each Direction (Inbound / Outbound)
• Bandwidth Borrowed
• Temporary (5 minute) Quick Blocking of any LAN Client
• Bandwidth / Session Limitation

Network/Router Management:

• Web-Based User Interface (HTTP / HTTPS)
• CLI ( Command Line Interface ) / Telnet / SSH
• Administration Access Control
• Configuration Backup / Restore
• Built-in Diagnostic Function
• Firmware Upgrade via TFTP / FTP
• Logging via Syslog
• SNMP v3 Management with MIB-II
• TR-069
• TR-104

VPN Facilities:

• Up to 32 Concurrent VPN Tunnels (incoming or outgoing)
• Tunnelling Protocols: PPTP, IPSec, L2TP, L2TP over IPSec
• IPSec Main and Agressive modes
• Encryption : MPPE and Hardware-Based AES / DES / 3DES
• Authentication : Hardware-Based MD5 and SHA-1
• IKE Authentication : Pre-shared Key or X.509 Digital Signature
• SSL VPN for teleworkers - Up to 5 simultaneous users. Proxy or tunnel
• LAN-to-LAN & Teleworker-to-LAN connectivity
• DHCP over IPSec
• NAT-Traversal (NAT-T)
• Dead Peer Detection (DPD)
• VPN Pass-Through
• MOTP (Mobile One Time Password)

Routing Protocols::

• Static Routing
• RIP V2

Bandwidth Management:

• QoS
• Guaranteed Bandwidth for VoIP
• Class-based Bandwidth Guarantee by User-Defined Traffic Categories
• Layer 2&3 (802.1p & TOS/DCSP)
• DiffServ Code Point Classifying
• 4-level Priority for each Direction (Inbound / Outbound)
• Bandwidth Borrowed
• Temporary (5 minute) Quick Blocking of any LAN Client
• Bandwidth / Session Limitation

Operating Requirements:

• Rack Mountable (Optional Vigor RM1 mounting bracket required)
• Wall Mountable
• Temperature Operating : 0°C ~ 45°C
• Storage : -25°C ~ 70°C
• Humidity 10% ~ 90% (non-condensing)
• Power Consumption: 18 Watt Max.
• Dimensions: L240.96 * W165.07 * H43.96 ( mm )
• Operating Power: DC 15V (via external PSU, supplied)
• Warranty : Two (2) Years RTB
• Power Requirements : 220-240VAC
