Fanvil i10SV SIP Mini Intercom (i10SV)

0 Based on 0 ratings.
Write a Review
28/12/2024 £77.90 exc. VAT
£93.48 inc. VAT
Availability:In stock for next day delivery
Qty:
Key Features
  • IP54 waterproof and dustproof
  • Easy installation and configuration
  • Built-in 1W speaker and AEC with 1080p Camera

Pricing Volume Price Discounts

5+ £76.70
10+ £75.60
25+ £74.50

Shipping Shipping Options

Shipping costs are calculated based on weight and destination during checkout. For next day delivery our cut off is 16:00.

Support Product install/setup

Want help installing this product? Add premium support to your order.

Downloads Documents & Manuals

SKU:i10SV
Brand: Fanvil
Available Options:
  • Product Details
  • Reviews
  • White Papers / Case Studies

Fanvil i10SV SIP Mini Intercom (i10SV)

The i10SV SIP Mini Intercom is purpose-built for indoor applications, featuring an IP54 waterproof and dustproof design that ensures reliability in challenging environments. Tailored for seamless wall mounting, this compact intercom combines security, audio/video intercom, and broadcasting functionalities to deliver a comprehensive communication solution. Its adaptability and robust features make it an ideal choice for users seeking a reliable and versatile system in various indoor settings.

Fanvil i10SV Key Features

  • Easy installation and configuration.
  • IP54 waterproof and dustproof.
  • -20 °C to 50 °C wide range temperature adaptability.
  • Built-in 1W speaker and Acoustic Echo Canceller (AEC).
  • Built-in 1short circuit input/output interface.
  • Functionality including security, intercom and broadcasting.
  • Built-in HD camera and with backlight compensation function.
  • Adaptive 10/100 Mbps network port, integrated PoE.
  • Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc.

This innovative intercom system not only prioritizes security but also enhances user experience through clear audio/video capabilities. Whether deployed in residential or commercial spaces, the i10SV stands out as a compact yet powerful communication solution, offering a sophisticated blend of features in a user-friendly package.

i10SV Management

Fanvil i10SV Technical Specifications

General

  • 2 SIP lines
  • Speed dial
  • Linkage with IP camera to realise video intercom
  • Oral announcement of the IP address(in English)
  • Switch signal input and output
  • Support programmable DSS key ports
  • PoE enabled

Device Functions

  • Auto-answering
  • Programmable DSS keys
  • Through web page volume adjustment
  • Network time synchronization
  • Time plan (task management)
  • Dynamic multicast function
  • Incoming call multicast
  • HTTP API
  • Action URL / Active URI

Call Functions

  • Call out / answer / reject
  • Call waiting
  • Intercom, Multicast
  • Speed dial
  • Anonymous call (Hide caller ID)

Audio

  • Narrowband codec: G.711A/U, G.729A/B, iLBC, G.723, G.726-32K
  • Wideband codec: G.722, Opus
  • Full-duplex hands-free speakerphone with AEC
  • DTMF: In-band, Out-of-Band (RFC2833/ SIP INFO)

Video

  • Sensor: 1/5" color CMOS
  • Pixels: 2 Mega
  • Video coding: H.264
  • Resolution: 720P, 1080P
  • Minimum illumination: 40%
  • Viewing angle: Diagonal: 73° / Horizontal: 63.3° / Vertical: 49.6°

Networking

  • Physical: 10/100 Mbps Ethernet
  • IP mode:IPv4/IPv6/IPv4&IPv6
  • IP configuration: Static IP / DHCP / PPPoE
  • VPN: L2TP / OpenVPN
  • VLAN
  • LLDP
  • Qos

Deployment and Management

  • Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
  • Web management portal
  • Web-based packet dump
  • Configuration export / import
  • Firmware upgrade
  • Syslog

Physical Specification

  • DSS Keys, follow model
  • i10S/i10SV: 1 DSS key (speed dial key)
  • i10SD: 2 DSS keys
  • RJ45 port x1: connect the network
  • WAN port: connect the network, Power over Ethernet (IEEE 802.3af), class 3
  • Short circuit input and output port x1 (built-in relay)
  • Relay: MAX DC30V / 1A, AC125V / 0.5A
  • Port: terminal socket
  • DC port: DC power input
  • DC power input: DC12V / 1A
  • Port: terminal socket
  • Protection level: IP54
  • Housing material: ABS
  • Installation: Wall-mounted
  • Working temperature: -20℃~ 50℃
  • Storage temperature: - 30℃~ 60℃
  • Working humidity: 10~95%
  • Device dimensions: 88x88x32 mm
  • Gift box dimensions: 95x108x40 mm
  • Outer CTN dimensions: 241x225x215 mm (20 PCS)

Specifications Tab
