Sangoma EXP100 Expansion Module

0 Based on 0 ratings.
Write a Review
06/01/2025 £111.70 exc. VAT
£134.04 inc. VAT
Availability:In stock for next day delivery
Qty:
Key Features
  • 160x320 Graphic LCD display
  • 2x RJ45 Ports
  • Wall Mountable

Pricing Volume Price Discounts

No volume pricing discounts available

Shipping Shipping Options

Shipping costs are calculated based on weight and destination during checkout. For next day delivery our cut off is 16:00.

Support Product install/setup

Want help installing this product? Add premium support to your order.

Downloads Documents & Manuals

SKU:PHON-EXP100
Brand: Sangoma
Available Options:
Available Product Options:
UK Power Supply Required?:
  • Product Details
  • Reviews
  • White Papers / Case Studies

Sangoma EXP100 Expansion Module (PHON-EXP100)

The Sangoma EXP100 Expansion Module is designed specifically for users who manage high call volumes, the Sangoma EXP100 expansion module delivers single-button access to contacts / extensions and maximizes productivity of the telephone attendant by efficiently dispatching inbound calls.

Sangoma EXP100 Key Features

  • Large 160x320 Graphic LCD Display
  • 20 Programmable Hard Keys for Up to 40
  • Programmable Features
  • 2 x Control Keys for Quickly Switching Pages
  • Daisy-chain Up to 6 Modules for Up to 240
  • Programmable Keys *Up to 50 BLFs
  • Compatible with Sangoma s500 & s700 IP Phones
  • Wall Mountable
  • 2x RJ45 Ports (1x Uplink & 1x Downlink)
The EXP100 is compatible with the Sangoma s500 and s700 series.

Physical Features
The Sangoma EXP100 features a large 160x320 graphic LCD displaywith 2 pages of 20 programmable hard keys delivering upto 40 programmable features. Dual-color LED and 2 controlkeys for fast page switching make the EXP100 simplify communications.

Expandability

Extend your investment by daisy-chaining up to 6 expansion modules for up to 240 programmable keys.


(Phone Not included)

Sangoma EXP100 Expansion Module - Technical Specifications

PSTN Protocols

  • 160x320 graphic LCD with 16-level grayscales
  • LCD backlight
  • Two page views are possible
  • Different icons for each function shown on the LCD
  • Local GUI controlled by host Sangoma s500 / s700 phone

Feature Keys

  • 20x physical keys each with a dual-color LED
  • 20x additional keys through page switch
  • 2x independent control keys
  • 20x additional keys through page switch
  • Daisy-chain up to 6 modules for up to 240
  • programmable keys *Up to 50 BLFs

Certication

  • EMC: FCC Part 15 Class B, EN 55022, EN 55024,EN 61000
  • Safety: EN 60950

Connectivity

  • 2x RJ45 ports (1x uplink and 1x downlink)

Environmental

  • Operating humidity: 10~95%
  • Operating temperature: -10~50°C

Dimensions

  • Box Size: 140mm (W) x 251mm (D) x 91mm (H)
  • Shipping Weight: 1.18kgs (2.6lbs)

Power

  • Power provided by host phone via EHS port when using
    up to 1 expansion module
  • External universal AC adapter *Optional
    AC 100~240V input
    DC 5V/1.2A output
