Benefits

• High-resolution 4.3" TFT-colour display
• Dedicated displays for extension monitoring
• Up to 24 BLF keys (6 physical)
• Improved graphical user interface
• Dual-angle footstand: 46° and 28°
• Wall mountable
• Wideband hands-free talking
• Digital Signal Processor (DSP) ehanced audio quality
• 2-port 1-Gigabit Ethernet switch (RJ45) IEEE 802.3
• Power over Ethernet IEEEaf, Class 3
• USB headset ready
• D7 Expansion Module ready
• Support for USB WiFi stick
• Electronic Hook Switch (EHS) support for wireless headsets
• Built-in Bluetooth compatibility

Firmware Features

• 12 SIP identities / accounts
• XML browser
• Call lists for dialed, received and missed calls
• Local directory with 10000 entries
• Multiple language support
• DTMF in-band / out-of-band / SIP-INFO
• Interoperable with all major IP PBX platforms

Call Features

• Speed dialing
• URL dialing
• Local dial plan
• Automatic redial on busy
• Call completion (busy/unreachable)
• Caller identification
• Call waiting
• Call blocking (deny list)
• Auto answer
• Hold
• Music on hold
• Handling of up to 4 simultaneous calls
• Blind and attended transfer
• Call forwarding
  3-way conferencing on the phone
• Extension monitoring, call pickup
• Call park, call unpark
• Multicast paging
• DND mode (do not disturb)
• Keyboard lock
• Client matter code (CMC)

Audio

• Codecs
• G711 A-Law, µ-law
• G.722 (wideband)
• G.726, G.729AB, GSM 6.10 (FR)
• Built-in assignable ringtones
• Comfort Noise Generator (CNG)
• Voice Activity Detection (VAD)

Setup

• Configurable through web interface
• Provisioning:

  • Automatic loading of settings via HTTP/HTTPS/TFTP
  • DHCP Options 66/67
  • Snom Redirection Service
  • Remote management via TR-069 / TR-11

Protocols

• SIP (RFC3261)
• DHCP, NTP
• HTTP / HTTPS / TFTP
• LDAP (Directory)
• Dual Stack IPv4 / IPv6

User Interface

• Localisation (language, time, dial tone)
• Red LED for call indication /message waiting
• 4 context-sensitive keys
• 6 programmable line / function keys with multicolour LEDs
• Dedicated keys for: Message; DND, Directory, Menu, Transfer; Hold, Page switch
• Audio keys with LED indicator: Mute, Speakerphone, Headset
• Volume key
• 5-way navigation key
• OK and Cancel keys
• Menu-driven user interface

Security

• 802.1X authentication and EAPOL
• Transport layer security (TLS)
• SRTP (RFC3711), SIPS, RTCP
• HTTPS server/client
• Password-protected web interface
• VPN-support
• VLAN (IEEE 802.1Q)
• LLDP-MED, RTCP-XR

Phone Features

• Dimensions (approx):

  • 230 x 205 x 90 mm (LxWxD) w/o foot stand
  • 190 x 205 x 200/220 mm (LxWxD) with food stand
• Weight (approx.) device 750 g, footstand 140g
• Input voltage (5Vdc) (SELV)
• Power supply: PoE or 5Vdc power adapter, 10 Watts
• Handset: 4P4C
• Headset: 4P4C; 4pin for Snom EHS Advanced
• Hearing-aid compatible (HAC) handset
• 1x USB 2.0 host port, Type A, Hi/Full/Low-Speed
• Environmental conditions:

  • Ambient temperature: 0°C to 35°C (32°F to 95°F)
  • Storage temperature: -10°C to 45°C (14°F to 113°F)
  • Humidity: 5% to 95% (non condensing)
• Included delivery

  • Phone unit
  • Footstand
  • Handset with cord
  • Ethernet cable
  • Quick Start Guide
• Colour: Black
• Warranty: 2 Years

Type Approvals

• CE Mark
• FCC Class B
• Safety IEC 60950, CB
