Basics and Equipment

• Product Information
  • Guest room phone | Corded handset | PN 00007010
  • Colour: Gunmetal Black
• Equipment
  • Anti-bacterial Housing
  • Sturdy, Solid Construction
  • Fully Customizable Faceplate for Hotel Branding and Dialing Instructions
• Placement: Indoor, Desktop, Nightstand, Wall Mounting

Dimensions and Weight

• Dimensions (H x W x D, Approx.)
  • Corded handset (on the base cradle, desk mounted): 182 mm × 53 mm × 146 mm
  • Corded handset (on the base cradle, wall mounted): 216 mm × 53 mm × 56 mm
• Weight (Approx.)
  • Corded handset (on the base cradle): 400 g

Indicators and Keys

• Telephone Base: 3 LED Indicators
  • Call status indication|Message waiting indication (MWI): 1 red LED
  • Mute Status Indication: 1 Red LED
  • Speakerphone Mode: 1 Red LED
• Corded handset: 20 hard keys in total
• 12 keys (standard ITU telephone keypad)
• 4 dedicated audio keys
  • Mute (with red LED)
  • Speakerphone mode (with red LED)
  • VOL+ → Volume +
  • VOL- → Volume -
• 1 dedicated function key: Message
• 3 programmable function keys: Speed dialling

Audio Devices and Features

• Corded Handset
  • Microphone
  • Handset Earpiece
  • Hearing Aid Compatible (HAC)
  • Built-in Assignable Ringtones
  • External speaker

Interfaces and Connections

• Power Options
  • Power over Ethernet (PoE)
    • IEEE 802.3at, Class 2
• Wired Interfaces
  • Telephone base
    • Network connectivity: RJ45-8P8C socket → Gigabit Ethernet (GbE)
    • Handset cord: custom socket
  • Corded handset
    • Handset cord: custom socket

Interoperability

• Interoperable with all major IP-PBX platforms

Administration interfaces and setup

• Configuration and setup via voice menu
• Advanced SIP configuration tool for easy mass deployment and phone monitoring

Networking Technologies and Protocols

• VLAN Support: SIP (RFC 3261)

Call Features

• 1 SIP Identity / Account
• Mute Microphone (via Dedicated Function Key)
• Speed Dialling via Function Keys
• Multicast Paging

Environmental Conditions

• Operating Ambient Temperature: 5 °C - 45 °C
• Humidity (Non-Condensing): 5% - 95%

Package Contents

• Hardware
  • Telephone Base
  • Handset
  • Handset cord: 330 mm
  • Footstand
  • Wall Mount Kit
  • 2 Ethernet Cables:
    • Cable Length (Approx.): 140 mm | 2 m
• Documentation
  • Quick Installation Guide (QIG)

Snom Accessories and Compatible Devices

• PoE injector: A5 (PN 00004065)
